Auto-Tuned Pid Temperature Controller

Auto-Tuned Pid Temperature Controller

MODEL NUMBER: 102, 103, 104, 107

Temperature controller with unique features to provide a precise control with Automatic PID tuning. Microcontroller based instrument with single 4-digit display for real time and set value temperature. Soft keys provided on front of the panel for easy setting with password protection.

INPUT Selectable - Thermocouple (J, K, R, S, T, E, N) & RTD (PT-100)
OUTPUT 2 Relays ( NO ) Contact: 5A @ 230V AC or SSR (Optional)
DISPLAY 4 Digit 0.56” High Bright Seven Segment LED
DISPLAY RANGE -200 TO +1800 °C
RESOLUTION 1 °C or 0.1 °C Selectable
POWER SUPPLY 230 V AC ± 15 % ( consumption < 5 Watts )
DISPLAY ACCURACY 0.3 % F.S. +  ±1 count
CONTROL ALGORITHM ON / OFF control or Auto-tuned PID control, software selectable
ENCLOSURE SIZE (mm) 96X96X65, 72X72X65, 48X96X65
AMBIENT TEMPERATURE 0-60 °C
STORAGE TEMPERATURE 0-70 °C
HUMIDITY 0-95 % RH ( non-condensing )
